Wilson and Bradley hinge systems combine cutting-edge engineering with functional design. Our hinges offer reliability, enhanced adjustability, and simple assembly—all while maintaining an attractive look. With the ability to make 3-dimensional adjustments, they deliver high performance in a variety of applications.
Designed for durability, our hinges are tested to withstand 200,000 opening and closing cycles. They are ideal for wood, glass, aluminum, and both thin and thick doors. Specialized solutions are available for applications such as blind corners and angled doors.
The CLIP top BLUMOTION feature ensures a smooth, controlled closing action for every door, regardless of its size, weight, or the force used. The mechanism can be adjusted or deactivated on one or both hinges for precise control over closing speed. Doors are easily attached and detached thanks to the CLIP technology, and the hinges provide simple three-dimensional and cam adjustments.
TheCLIP mechanism is proven to make assembly quick and tool-free, making it easier than ever to install and adjust hinges while ensuring a smooth, reliable operation.
Features:
Tested to endure over 200,000 cycles of opening and closing
Versatile for various door materials and applications
3-dimensional adjustment for precise alignment
Simple, tool-free assembly and adjustment
Specifications:
Application: Angled hinge
Cranking: Half overlay
Opening Angle: 95°
Closing Mechanism: Spring-assisted
Hinge Variant: Integrated BLUMOTION
Cover Cap Types: 90M2603, 70.1553
Boss Material: Steel, Nickel-plated finish
Boss Assembly: INSERTA
Flange Width: 57mm
Flange Length: 27.5mm
Flange Height: 6.4mm
Hinge Boss Drilling Diameter: 35mm
Fixing Holes Diameter: 8mm
Distance Between Drillings: 45mm
Eccentric Position of Fixing Holes to Boss Hole: 9.5mm
