How distinctive would you like your LEGRABOX drawers to be? You can choose from three design options. LEGRABOX Pure and LEGRABOX Free offer a selection of standard colours with a premium anti-fingerprint stainless steel finish.
For a more striking, coordinated style, explore the LEGRABOX Special Edition, a colour-matched range featuring refined carbon black matt tones for a sleek, modern look.
LEGRABOX combines elegant design, advanced technology, and effortless usability. Its standout feature is the exceptional design freedom provided by this versatile box system.
Features
Slim, contemporary side panel design
Finished in distinctive Orion Grey coating
Supports dynamic loads up to 40 kg
Fully compatible with all LEGRABOX components
Backed by a lifetime warranty on all Blum products
Specifications
Type of box: LEGRABOX drawer side
Material: Steel
Drawer side height: K (128.5 mm)
Design option: Pure
Design: Plain
Nominal length: 500 mm
Connection drawer side to front: Front fixing bracket
Connection drawer side to back: Clip-on (steel back or wooden back bracket fixing bracket)
Internal drawer length (drawer side hat): 439.8 mm
Installation dimension (inner carcass depth to outer base edge): 17 mm
Height adjustment: Yes
Fixing of base to drawer side: Prong connection or screw-in
Bottom thickness: 16 mm
Finish of back fixing bracket: Orion Grey Matt
Stay-open stop: No
Minimum internal cabinet depth: 453 mm
Additions: ZA7.070 external cover caps (included)
Additions: ZA7.570 inner cover caps (included)
Item package: Right + Left drawer sides
Packaging: Commercial packing
Drawer type: Full extension
Dynamic load bearing drawer side/drawer profile: 40 kg
