Blum REVEGO duo Track Fixing Set. Right. 802M0002.R2 by W&B

Track Fixing by Wilson and Bradley – for REVEGO duo

Type: Track Fixing
Application: for REVEGO duo
Material: Steel
Colour / Finish: Zinc plated
Item Package: set

Required Accessories (sold separately):

• Blum System Screw, Countersunk Head 6 x 14.5 mm (6611450HG) – must be used
• Door Straightener CBR04DS – recommended for all REVEGO uno & duo pocket systems

Notes:

• Internal dimensions (width x height x depth) determine the maximum space for internal construction
• Design the widest front first for combined applications
• Certified durability: 40,000 opening and closing cycles
• Manual operating force under 70 N (per durability test)
• Drilling patterns, cut-to-size dimensions, and detailed parts lists available in the Blum Product Configurator

Assembly:

• CNC machine or MINIPRESS top with EASYSTICK from Blum required to machine wooden parts
• Both horizontal drillings and a track cut-out are needed
• Blum recommends using the drilling template for REVEGO pocket connectors for horizontal drillings
